Hand Scan Double Touch Switch Single Color Time Display 2A 24W

Upgrade your bathroom mirror with this Hand Scan Double Touch Switch with Single Color Control and Time Display, featuring innovative hand wave technology, dual-button touch functionality, and a convenient digital clock. Specially designed for smart LED mirrors, vanity mirrors, and modern bathrooms where touch-free operation and timekeeping are desired.

This advanced switch combines hand scan gesture control with dual-button touch functionality, a single fixed color temperature, and a built-in digital time display. Simply wave your hand to control your mirror lighting without touching anything – perfect for when your hands are wet. The unit delivers 12V output at 2A (24W) for your LED mirror lights with a consistent color temperature.

With hand scan gesture control, double touch buttons, and time display, it supports:

• Hand wave gesture: Turn ON/OFF with a simple wave
• Double touch buttons: Manual override control
• Hand hover: Stepless dimming (0-100%)
• One fixed color temperature (choose: 3000K Warm / 4000K Natural / 6500K Cool)
• Digital time display (12/24 hour format)
• Memory function – remembers last brightness setting
• DC12V input for flexible installation
• 24W power capacity (2A) for medium-sized mirrors
• Touch-free operation with manual backup

Key Features

• Hand Scan Gesture Control – Revolutionary touch-free operation! Simply wave your hand in front of the sensor to turn your mirror lights on or off. Hover your hand to activate stepless dimming. Perfect for bathrooms when hands are wet, soapy, or covered in makeup. No physical contact needed for hygienic operation.

• 24W Higher Power Capacity – Handles up to 24W LED load at 12V output (2A). Perfect for medium-sized bathroom mirrors, vanity mirrors, and lighting installations requiring more brightness than standard 12W models.

• Digital Time Display – Built-in LCD/LED display shows current time. Adds functionality and a modern touch to your bathroom mirror. Perfect for checking time while getting ready. 12/24 hour format selectable via button combination.

• Double Touch Backup Buttons – Two independent touch buttons provide manual control when preferred. Use them as a backup to gesture control or for precise adjustments. Intuitive and easy to use for the whole family.

• Touch-Free Stepless Dimming – Hover your hand over the sensor to activate smooth brightness adjustment from 0-100%. Move your hand up or down within the detection zone to increase or decrease brightness. Completely hands-free operation for perfect ambiance control.

• One-Color Fixed Temperature – Consistent color temperature (choose: 3000K Warm / 4000K Natural / 6500K Cool) for reliable, professional lighting. Simple and intuitive for everyday use.

• Smart Memory Function – No need to readjust your settings every time. The switch remembers your last brightness level, turning on the light exactly as you prefer it.

• Gesture Recognition Technology – Advanced sensor detects hand movements accurately and reliably. Works through glass and acrylic (1-6mm thick) for invisible installation behind your mirror.

• IP21 Water Resistant – Splash-proof design engineered for bathroom environments. Safe for use behind mirrors and in humid conditions.

• Compact Design – Compact footprint fits easily behind any mirror. Dimensions: 3.0″ × 1.8″ × 0.5″ (76 × 46 × 13mm) approx.

• 2 Installation Options – 3M adhesive pad (no drilling) or mounting screws (permanent installation).

• All-Climate Operation – Works in -40°F to 167°F (-40°C to 75°C). Perfect for all USA climates.

• Long Lifespan – Rated for 100,000+ switching cycles. Built to last for years.

Technical Specifications

Electrical
• Product Type: Hand Scan Double Touch Switch with Time Display
• Input Voltage: DC 12V
• Output Voltage: DC 12V
• Output Current: 2A max
• Output Power: 24W max
• Dimming Range: 0-100% stepless via hand hover
• Color Temperature: One-color fixed (specify: 3000K Warm / 4000K Natural / 6500K Cool)
• Standby Power: Less than 0.5W
• Memory Function: Yes – remembers last brightness

Display Features
• Display Type: Digital LCD/LED
• Time Display: 12/24 hour format (selectable)
• Format Setting: Via button combination (see manual)

Gesture & Touch Control
• Gesture Control: Hand scan recognition
• Detection Distance: 1-4 inches (2-10cm)
• Single Wave: Turn ON/OFF
• Hand Hover: Activate dimming mode
• Touch Buttons: Dual capacitive touch for manual backup
• Touch Functions: Single tap ON/OFF, touch & hold dimming

Physical
• Dimensions: 3.0″ × 1.8″ × 0.5″ (76 × 46 × 13mm) approx.
• Weight: 46g (1.62 oz)
• Color: Black / White (specify available options)
• Protection Rating: IP21 (splash-proof)
• Operating Temperature: -40°F to 167°F (-40°C to 75°C)
• Sensing Through: Works through glass/acrylic (1-6mm)

Package Includes

• 1x Hand Scan Double Touch Switch Unit – Combined gesture sensor, dual touch buttons, single-color control, and time display
