Upgrade your bathroom mirror with this Single Touch Switch with Hand Scan Gesture Control – Three Color Version, featuring innovative hand wave technology and a built-in power driver. Specially designed for smart LED mirrors, vanity mirrors, and modern bathrooms where touch-free operation and color temperature control are desired.
This advanced switch combines hand scan gesture control with a built-in universal power driver that accepts AC90-250V input, eliminating the need for a separate LED driver. Simply wave your hand to control your mirror lighting without touching anything – perfect for when your hands are wet or messy. The three-color version allows you to choose between warm, natural, and cool white light. The unit delivers 12V output at 1A (12W) for your LED mirror lights.
With hand scan gesture control, three-color options, and integrated power driver, it supports:
• Hand wave gesture: Turn ON/OFF with a simple wave
• Hand hover: Stepless dimming (0-100%)
• Double wave: Cycle through three color temperatures
• Three color temperatures: Warm (3000K), Natural (4500K), Cool (6500K)
• Memory function – remembers last color and brightness setting
• Built-in power driver – no external driver needed!
• Universal AC input: 90-250V works worldwide (USA 120V ready)
• 12W power capacity (1A) for small to medium mirrors
• Touch-free operation – no physical contact needed
Key Features
• Hand Scan Gesture Control – Revolutionary touch-free operation! Simply wave your hand in front of the sensor to turn your mirror lights on or off. Hover your hand to activate stepless dimming. Double wave to cycle through three color temperatures. Perfect for bathrooms when hands are wet, soapy, or covered in makeup. No physical contact needed for hygienic operation.
• Three-Color Temperature Control – Choose between Warm (3000K), Natural (4500K), and Cool (6500K) white light. Perfect for creating different moods and for accurate makeup application. Double wave your hand to cycle through colors effortlessly.
• Built-in Universal Power Driver – No need for a separate LED driver! This all-in-one unit connects directly to your household power (AC90-250V). Delivers 12W of power at 12V (1A) for mirror installations. Works perfectly with USA 120V and international 230V systems. Simplifies installation and saves space behind your mirror.
• Touch-Free Stepless Dimming – Hover your hand over the sensor to activate smooth brightness adjustment from 0-100%. Move your hand up or down within the detection zone to increase or decrease brightness. Completely hands-free operation for perfect ambiance control.
• 12W Power Capacity – Handles up to 12W LED load at 12V output (1A). Perfect for small to medium bathroom mirrors, vanity mirrors, and accent lighting installations.
• Smart Memory Function – No need to readjust your settings every time. The switch remembers your last color temperature and brightness level, turning on the light exactly as you prefer it.
• Gesture Recognition Technology – Advanced sensor detects hand movements accurately and reliably. Works through glass and acrylic (1-6mm thick) for invisible installation behind your mirror.
• IP21 Water Resistant – Splash-proof design engineered for bathroom environments. Safe for use behind mirrors and in humid conditions.
• Compact Design – Compact footprint fits easily behind any mirror. Dimensions: 2.6″ × 1.8″ × 0.8″ (66 × 46 × 20mm) approx.
• 2 Installation Options – 3M adhesive pad (no drilling) or mounting screws (permanent installation).
• All-Climate Operation – Works in -40°F to 167°F (-40°C to 75°C). Perfect for all USA climates.
• Long Lifespan – Rated for 100,000+ switching cycles. Built to last for years.
Technical Specifications
Electrical
• Product Type: Hand Scan Touch Switch with Built-in Driver – Three Color Version
• Input Voltage: AC 90V – 250V (universal, works worldwide)
• Output Voltage: DC 12V (regulated)
• Output Current: 1A max
• Output Power: 12W max
• Dimming Range: 0-100% stepless via hand hover
• Color Temperatures: 3000K (Warm), 4500K (Natural), 6500K (Cool)
• Standby Power: Less than 0.5W
• Memory Function: Yes – remembers last color and brightness
• Frequency: 50/60Hz (auto-sensing)
Gesture Control Specifications
• Control Type: Hand scan gesture recognition
• Detection Distance: 1-4 inches (2-10cm)
• Single Wave: Turn ON/OFF
• Double Wave: Cycle through color temperatures
• Hand Hover: Activate dimming mode
• Gesture Range: Adjustable sensitivity
Physical
• Dimensions: 2.6″ × 1.8″ × 0.8″ (66 × 46 × 20mm) approx.
• Weight: 66g (2.33 oz)
• Color: Black / White (specify available options)
• Protection Rating: IP21 (splash-proof)
• Operating Temperature: -40°F to 167°F (-40°C to 75°C)
• Sensing Through: Works through glass/acrylic (1-6mm)
Package Includes
• 1x Hand Scan Switch Unit – Combined gesture sensor, three-color control, and 12W power driver
