YZKJ-B3-OTTC Dual Touch Switch Three Color DC12V 60W Temperature Display LED Light Defogger Mirror Touch Sensor Stepless Dimmer Switch Inductive Switches

Upgrade your bathroom mirror with this YZKJ-B3-OTTC Dual Touch Switch Three Color Version with Temperature Display & Defogger, specially designed for smart LED mirrors, anti-fog mirrors, and mirror cabinets. This advanced all-in-one unit features a high-power 60W built-in driver that works with DC12V input, eliminating the need for a separate LED driver in many installations.

This sophisticated dual touch sensor switch features two independent buttons with three color temperature control, integrated defogger control, and a digital display showing temperature. The unit accepts DC12V input and delivers 60W of power, making it perfect for large bathroom mirrors and commercial installations.

With dual-key touch control and integrated features, it supports:

• Left key: LED light On/Off, stepless dimming (0-100%), and color temperature cycling
• Right key: Mirror defogger On/Off control
• Digital display: Shows current temperature (°C/°F selectable)
• Three color temperatures: Warm (3000K), Natural (4500K), Cool (6500K)
• Memory function – remembers last color and brightness setting
• Built-in 60W power driver – efficient power management
• DC12V input for flexible installation
• High 60W power capacity for large, bright mirrors

Key Features

• Built-in 60W High-Power Driver – Efficient built-in driver delivers 60W of power at 12V (5A) for large and extra-bright mirror installations. Simplifies installation and saves space behind your mirror.

• Digital Temperature Display – Built-in LCD/LED display shows current room temperature. Adds functionality and a modern touch to your bathroom mirror. Perfect for checking temperature while getting ready. Switch between °C and °F.

• Dual Touch Convenient Control – Two independent buttons for separate control of LED light and mirror defogger. Intuitive and easy to use for the whole family.

• Three-Color Temperature Control – Choose between Warm (3000K), Natural (4500K), and Cool (6500K) white light. Perfect for creating different moods and for accurate makeup application. Double tap left button to cycle through colors.

• Built-in Defogger Control – Dedicated right button for mirror defogger. Keep your mirror clear from steam and fog during hot showers. Simple and effective on/off operation.

• 60W High Power Capacity – Handles up to 60W LED load at 12V output (5A). Perfect for large bathroom mirrors, commercial installations, hotel bathrooms, and mirrors with high LED density requiring maximum power.

• Stepless Dimming 0-100% – Smooth brightness adjustment for any color temperature. Tap left key to turn on/off, touch and hold to dim up and down. Create the perfect ambiance for any time of day.

• Color Temperature Cycling – Double tap left button to cycle through three color temperatures. Find the perfect lighting for any activity.

• Memory Function – Remembers your last color temperature and brightness setting. No need to readjust every time you turn on the light.

• IP21 Water Resistant – Splash-proof design engineered for bathroom environments. Safe for use behind mirrors and in humid conditions.

• Capacitive Touch Technology – Advanced sensor responds to lightest touch. Works perfectly through glass and acrylic (1-6mm thick).

• Compact All-in-One Design – Despite the high 60W power capacity, the unit maintains a compact footprint combining controller, power driver, and display in one unit. Fits easily behind any mirror.

• 2 Installation Options – 3M adhesive pad (no drilling) or mounting screws (permanent installation).

• All-Climate Operation – Works in -40°F to 167°F (-40°C to 75°C). Perfect for all USA climates.

• Long Lifespan – Rated for 100,000+ switching cycles. Built to last for years.

• YZKJ Quality – Reliable brand known for innovative mirror lighting solutions.

Technical Specifications

Electrical
• Model: YZKJ-B3-OTTC
• Input Voltage: DC 12V
• Output Voltage: DC 12V
• Output Current: 5A max
• Output Power: 60W max
• Dimming Range: 0-100% stepless
• Color Temperatures: 3000K (Warm), 4500K (Natural), 6500K (Cool)
• Standby Power: Less than 0.5W
• Memory Function: Yes – remembers last color and brightness

Display Features
• Display Type: Digital LCD/LED
• Temperature Display: °C / °F selectable
• Temperature Range: -40°F to 167°F (-40°C to 75°C)
• Accuracy: ±1°C / ±2°F

Physical
• Dimensions: 3.5″ × 2.1″ × 1.1″ (89 × 53 × 28mm) approx.
• Weight: 96g (3.4 oz)
• Color: Black / White (specify available options)
• Protection Rating: IP21 (splash-proof)
• Operating Temperature: -40°F to 167°F (-40°C to 75°C)
• Sensing Range: 1-6mm (works through glass/acrylic)

Sensor Technology
• Type: Capacitive touch sensor
• Response Time: Less than 100ms
• Touch Cycles: 100,000+ times
• Activation: Light touch through glass

Button Functions
• Left Button: LED light control
– Single tap: Turn ON/OFF
– Touch & hold: Stepless dimming (0-100%)
– Double tap: Cycle through color temperatures (3000K → 4500K → 6500K)
• Right Button: Defogger control
– Single tap: Turn ON/OFF
• Display: Shows temperature continuously when unit is powered

Perfect For: Large bathroom mirrors, commercial installations, hotel bathrooms, spa facilities, and any installation where dual-key control with three-color options, temperature display, defogger functionality, and maximum 60W power capacity is desired.

Package Includes

• 1x YZKJ-B3-OTTC All-in-One Unit – Integrated dual touch switch with temperature display, three-color control, defogger, and 60W driver
