YZKJ-Y1-36OC Single Touch Switch One Color Version Power Driver 3A 36W 12V AC90-250V Led Light Switch Bathroom Smart Control Sensor Mirror Touch Switch

Upgrade your bathroom mirror with this YZKJ-Y1-36OC Single Touch Switch One Color Version with Built-in Power Driver, specially designed for smart LED mirrors, vanity mirrors, and mirror cabinets. This all-in-one unit features a high-power 36W built-in driver that works with universal AC90-250V input, eliminating the need for a separate LED driver.

This sleek and modern touch sensor switch features one-color temperature control with a single touch button, allowing simple and intuitive control over your mirror lighting. The built-in power driver accepts wide voltage input from AC90V to 250V, making it perfect for worldwide use including USA (120V) and European (230V) installations.

With single-key touch control and integrated power driver, it supports:

• On/Off function
• One fixed color temperature (choose: 3000K Warm / 4000K Natural / 6500K Cool)
• Stepless dimming (0-100%)
• Memory function – remembers last brightness setting
• Built-in 36W power driver – no external driver needed!
• Universal AC input: 90-250V works worldwide
• High 36W capacity for larger, brighter mirrors

Key Features

• Built-in 36W Universal Power Driver – No need for a separate LED driver! This all-in-one unit connects directly to your household power (AC90-250V). Delivers 36W of power at 12V (3A) for larger and brighter mirror installations. Works perfectly with USA 120V and international 230V systems. Simplifies installation and saves space.

• High Power Capacity – 36W – Handles up to 36W LED load at 12V output (3A). Perfect for large bathroom mirrors, commercial installations, and mirrors with high LED density requiring more power.

• One-Color Fixed Temperature – Consistent color temperature (choose: 3000K Warm / 4000K Natural / 6500K Cool) for reliable, professional lighting. Simple and intuitive for everyday use.

• Single Touch Smart Control – One button controls all functions:
– Single tap: On/Off
– Touch & hold: Stepless dimming (0-100%)

• Stepless Dimming 0-100% – Smooth brightness adjustment. Create the perfect ambiance for any time of day – bright for makeup application, soft for relaxing baths.

• Memory Function – Remembers your last brightness setting. No need to readjust every time you turn on the light.

• IP21 Water Resistant – Splash-proof design engineered for bathroom environments. Safe for use behind mirrors and in humid conditions.

• Capacitive Touch Technology – Advanced sensor responds to lightest touch. Works perfectly through glass and acrylic (1-6mm thick).

• Ultra-Compact All-in-One Design – Compact footprint combining controller and high-power driver in one unit. Fits easily behind any mirror despite the higher power capacity.

• 2 Installation Options – 3M adhesive pad (no drilling) or mounting screws (permanent installation).

• All-Climate Operation – Works in -40°F to 167°F (-40°C to 75°C). Perfect for all USA climates.

• Long Lifespan – Rated for 100,000+ switching cycles. Built to last for years.

• YZKJ Quality – Reliable brand known for innovative mirror lighting solutions.

Technical Specifications

Electrical
• Model: YZKJ-Y1-36OC
• Input Voltage: AC 90V – 250V (universal, works worldwide)
• Output Voltage: DC 12V (regulated)
• Output Current: 3A max
• Output Power: 36W max
• Dimming Range: 0-100% stepless
• Color Temperature: One-color fixed (specify: 3000K Warm / 4000K Natural / 6500K Cool)
• Standby Power: Less than 0.5W
• Memory Function: Yes – remembers last brightness
• Frequency: 50/60Hz (auto-sensing)

Physical
• Dimensions: 2.8″ × 1.9″ × 0.9″ (71 × 48 × 22mm) approx.
• Weight: 75g (2.65 oz)
• Color: Black / White (specify available options)
• Protection Rating: IP21 (splash-proof)
• Operating Temperature: -40°F to 167°F (-40°C to 75°C)
• Sensing Range: 1-6mm (works through glass/acrylic)

Sensor Technology
• Type: Capacitive touch sensor
• Response Time: Less than 100ms
• Touch Cycles: 100,000+ times
• Activation: Light touch through glass

Button Functions
• Single Button Control:
– Single tap: Turn ON/OFF
– Touch & hold: Stepless dimming (0-100%)

Perfect For: Large bathroom mirrors, commercial installations, hotel bathrooms, spa facilities, LED vanity mirrors with high brightness requirements, backlit mirrors, mirror cabinets, and any application where higher power (36W) is needed for impressive illumination.

Package Includes

• 1x YZKJ-Y1-36OC All-in-One Unit – Integrated touch switch and 36W power driver with one-color control
