YZKJ-Y2-24LTC Double Touch Switch Three Color Version Antifog Power Driver 2A 24W 12V AC90-250V

Name: YZKJ-Y2-24LTC Double Touch Switch Three Color Version Antifog Power Driver 2A 24W 12V AC90-250V
SKU: 10158
Availability: InStock

$3.67

Upgrade your bathroom mirror with this YZKJ-Y2-24LTC Double Touch Switch Single Color Version with Antifog and Built-in Power Driver, specially designed for smart LED mirrors, anti-fog mirrors, and mirror cabinets. This all-in-one unit features a built-in driver that works with universal AC90-250V input, eliminating the need for a separate LED driver.

This sleek and modern touch sensor switch features double-key control with one fixed color temperature and integrated antifog defogger control. The built-in power driver accepts wide voltage input from AC90V to 250V, making it perfect for worldwide use including USA (120V) and European (230V) installations.

With double-key touch control and integrated power driver, it supports:

• Left key: LED light On/Off and stepless dimming (0-100%)
• Right key: Mirror defogger On/Off control
• One fixed color temperature (choose: 3000K Warm / 4000K Natural / 6500K Cool)
• Memory function – remembers last brightness setting
• Built-in power driver – no external driver needed!
• Universal AC input: 90-250V works worldwide
• 12W power capacity for small to medium mirrors

Key Features

• Built-in Universal Power Driver – No need for a separate LED driver! This all-in-one unit connects directly to your household power (AC90-250V). Delivers 12W of power at 12V (1A) for mirror installations. Works perfectly with USA 120V and international 230V systems. Simplifies installation and saves space.

• Double Touch Control with Antifog – Two independent buttons for separate control of LED light and mirror defogger. Intuitive and easy to use for the whole family. Dedicated defogger button keeps your mirror clear from steam and fog.

• 12W Power Capacity – Handles up to 12W LED load at 12V output (1A). Perfect for small to medium bathroom mirrors, vanity installations, and mirrors with standard LED density.

• One-Color Fixed Temperature – Consistent color temperature (choose: 3000K Warm / 4000K Natural / 6500K Cool) for reliable, professional lighting. Simple and intuitive for everyday use.

• Stepless Dimming 0-100% – Smooth brightness adjustment for LED light. Tap left key to turn on/off, touch and hold to dim up and down.

• Memory Function – Remembers your last brightness setting. No need to readjust every time you turn on the light.

• Built-in Antifog Defogger Control – Dedicated button for mirror defogger. Keep your mirror clear from steam and fog during hot showers. Simple on/off operation.

• IP21 Water Resistant – Splash-proof design engineered for bathroom environments. Safe for use behind mirrors and in humid conditions.

• Capacitive Touch Technology – Advanced sensor responds to lightest touch. Works perfectly through glass and acrylic (1-6mm thick).

• Compact All-in-One Design – Compact footprint combining controller and power driver in one unit. Fits easily behind any mirror.

• 2 Installation Options – 3M adhesive pad (no drilling) or mounting screws (permanent installation).

• All-Climate Operation – Works in -40°F to 167°F (-40°C to 75°C). Perfect for all USA climates.

• Long Lifespan – Rated for 100,000+ switching cycles. Built to last for years.

• YZKJ Quality – Reliable brand known for innovative mirror lighting solutions.

Technical Specifications

Electrical
• Model: YZKJ-Y2-24LTC
• Input Voltage: AC 90V – 250V (universal, works worldwide)
• Output Voltage: DC 12V (regulated)
• Output Current: 1A max
• Output Power: 12W max
• Dimming Range: 0-100% stepless
• Color Temperature: One-color fixed (specify: 3000K Warm / 4000K Natural / 6500K Cool)
• Standby Power: Less than 0.5W
• Memory Function: Yes – remembers last brightness
• Frequency: 50/60Hz (auto-sensing)

Physical
• Dimensions: 2.8″ × 1.4″ × 0.8″ (71 × 35 × 20mm) approx.
• Weight: 65g (2.3 oz)
• Color: Black / White (specify available options)
• Protection Rating: IP21 (splash-proof)
• Operating Temperature: -40°F to 167°F (-40°C to 75°C)
• Sensing Range: 1-6mm (works through glass/acrylic)

Sensor Technology
• Type: Capacitive touch sensor
• Response Time: Less than 100ms
• Touch Cycles: 100,000+ times
• Activation: Light touch through glass

Button Functions
• Left Button: LED light control
– Single tap: Turn ON/OFF
– Touch & hold: Stepless dimming (0-100%)
• Right Button: Defogger control
– Single tap: Turn ON/OFF

Perfect For: Small to medium bathroom mirrors, LED vanity mirrors, backlit mirrors, mirror cabinets, and any installation where separate light and defogger control with built-in driver is desired.
